• 13th generation Intel ® CoRE ™ i9/i7/i5 processors • Support for Windows 10 and Windows 11

RGD-LTP-I100

Detail

TECHNICAL SPECIFICATIONS


SystemWindows 10 and Windows 11
CPUIntel® Core™ i7-13700H Processor 24M Cache, up to 5.0 GHz
Memory16GB/32GB DDR5 MAX Optional:96G
StorageOptional: 128GB/256GB/512GB/1TB/2TB/4TB, Optional: Disk Wiper
Display

15.6inch，1920（RGB）*1080，Luminance, 500cd/㎡,Sunlight Readable Optional: OLED,

15.6inch 4K:3840*2160, Luminance 500cd/㎡

Communication

1000M Ethernet , Intel® Wi-Fi 6 802.11ax Bluetooth (v5.2) , 4G LTE mobile broadband

standard precision GNSS(GPS/GLONASS/Galileo) Optional: 5G LTE mobile broadband

KeyboardLED backlit membrane keyboard with Waterproof feature
Graphics ControllerIntel® Iris® Xe Graphics eligible 1.50 GHz, Optional:NVIDIA GeForce RTX3060
I/O Interface:

USB3.0*3 , Thunderbolt™ 4 Type-C *1 , RJ45*2, COM*2（Or COM*1+VGA*1), HDMI*1

Power aviation plug*1 , Earphone port*1, Grounding Post*1

Environmental Specification

Operating: -20℃ to 55℃ (Customizable: -40℃ to 55℃ )

Storage: -40℃ to 70℃ (Customizable：-50℃ to 70℃ ) Humidity:- 95% RH, non-condensing

Battery

Main battery capacity：155Wh,(pluggable), Auxiliary battery capacity：58Wh(non-removable)

AdapterInput voltage: AC100V~240V, 60/50Hz, Output voltage: DC19V, 9.47A
