| Product Features: |
| 1】With the ability to adapt to extreme environments, ensure device durability and data security |
| 2】Support GPS 2G/3G/4G/5G,GPS and Fingerprint for outdoor field operations. |
| 3】With CPU i5-1235U(i7 available),TDP15W,10-Cores, 12 thread, Main Speed:1.4GHz, Maxium speed: 4.4GHz |
| 4】Built-in 11.1V 8000mAH long-life battery |
| 5】The case is made of high-strength and high-quality full aluminum alloy |
| TECHNICAL SPECIFICATIONS： |
| Material | Full Aluminum Alloy |
| Dimension | 340*260*48mmmm(Excluing handel with wrap angle) |
| CPU | I5-1235U(i7 available),TDP15W,10-Cores, 12 thread, Main Speed 1.4GHz， |
| Maxium speed | 4.4GHz |
| Memory | DDR5 16GB 4800MHz |
| Extended SSD | 1TB SSD |
| Operating System | WIN11 PRO |
| FHD Display | 14 inch 16:9，Resolution: 1920*1080，Brightness: 1000cd/㎡ |
| Touch Pannel | Optional 10-Point Capacitive Screen, G+G, Corning Gorilla Glass; Hardness above 7H; Scratch-resistant; Supports glove touch |
| Camera | Front 5.0MP |
| Buttons | Power Button *1 |
| Speaker | Built in 8Ω/1W *2 |
| Microphone | Internal MIC *1 |
| Battery | 11.1V 8000mAH long-life battery |
| WIFI | WIFI6 802.11 AC AX WIFI6/BT5.1 |
| Bluetooth | BT5.1 |
| Support | 2G/3G/4G/5G,GPS and Fingerprint |
| Keyboard | US Layout Keyboard with Backlight. Other layout is optional |
| I/O Interfaces | USB2.0*1,USB3.0*2,TYPE-C,∮3.5mm Standard Earphone Jack *1,HDMI 2.0 Standard,RJ45*1 10M/100M/1000M adaptive,RJ45*1 10M/100M/1000M adaptive, Supports Gigabit Protocol, DB9 (RS232) *1,DC19V 4.74A ∮5.5mm Power port *1,Anti-theft Lock Slot *1, Right-side Cooling Vent *1,Support M.2-2280, PCIe interface*1 |
| Camera Indicator Light | *1 Constant white light when active, light off when inactive. |
| Power Indicator Light | *1 Constant blue light when power on, light off when off |
| Battery Indicator Light | *1 (Dual-color red/green) Red when charging, green when fully charged, blinking red for low battery, light off during discharge |
| Case Key Lock | *1 Red light on indicates caps lock on, off indicates caps lock off |
| Airplane Mode Indicator Light | *1 Red light on indicates airplane mode on, off indicates airplane mode off |
| Adapter | A DC input 100-240VAC0.5A50/60Hz,DC19V/4.74A 90W |
| Rugged Features | MIL-STD-810H: 1.2m drop resistance,Working temperature: -20 °C to 60 °C Storage temperature: -30 °C to 70 °C,Humidity: 95% Non-Condensing
|
| Color | Army green/Ice grey/Navy grey/Black |
