TECHNICAL SPECIFICATIONS
| CPU | Onboard Intel Core™ i5-4422E processor, dual-core four-thread, 1.8GHz (up to 2.9GHz), 3M Cache,22nm,25W,Onboard Intel Core™ i7-4700EQ processor, four cores and eight threads, 2.4GHz (up to 3.4GHz), 6M Cache, 22nm, 47W,Supports Intel Core™ i7/i5/i3 4th generation processors | | Chipset | On-board Intel QM87 PCH | | Memory | Onboard 8GB DDR3 SDRAM, Onboard 4GB DDR3 SDRAM (optional) | | BIOS | SPI Flash | | Graphics Card | Support 1-channel VGA+2-channel DVI graphics card, dual-channel independent graphics card | | Sorage |
2 x standard mSATA slots, SSD (4GB/8GB/16GB/32GB/64GB optional) | | Network Card |
4 x Intel I210 Gigabit network cards,each network card has exclusive PCIE×1 resource | | Sound Card: | Onboard 1x Realtek ALC892 | | OS | Windows7, Linux, VxWorks, XP, etc. | | Power Supply | Standard CPCI power supply, AT mode, automatic power-on/ATX mode, power on button (configurable) | | Dimension | 233mm x 160mm x 4HP | | Working Temperature | -20℃ ~ + 55℃, 0% ~ 90% non-condensing humidity, -40℃ ~ + 55℃, 0% ~ 90% non-condensing humidity (optional) | | Storage Temperature | -45℃ ~ + 75℃, 0% ~ 90% non-condensing humidity | | CPCI Interface | J1: 32-bit PCI local bus, J2: 64-bit PCI local bus, J3: Custom signal, J4: Custom signal, J5: Custom signal | | IO Resources | Front panel IO resources and buttons: Reset Button Post-IO resources: 4-channel USB 2.0, 4-channel RS-232, 2-channel DVI, 2-channel SATA2.0, 1-channel IDE, 1-channel PS/2,1 set of audio, 1 channel LPT, 1 channel FDD |
|
