Display Size: 13.3 inches, IPS wide viewing angle, with anti-glare AG glass
Screen Type: Flat Screen
Resolution: 1920*1080
Power Supply: DC18V-36V
Mounting Solution: Rack mount/Wall mount

RGD-DSP-A01303J-0001

Detail
TECHNICAL SPECIFICATIONS
Display Size13.3 inches, IPS wide viewing angle, with anti-glare AG glass
Screen TypeFlat Screen
Resolution1920*1080
Power SupplyDC18V-36V
Power Supply InterfaceDC24V input
Display Interface1*HDMI
MaterialAluminum Alloy
Cabinet ColorIce grey
Mounting SolutionRack mount/Wall mount
Working:Temperature-10℃～55℃
Storage Temperature-40℃～60℃
ESDContact Discharge: ±15KV,   Air Discharge: ±15KV
Electromagnetic Compatibility:
1, Meet MIL-STD-461G (EMC, EMI, EMS, ESD):
CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads
CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads
CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads
CS106 Conducted Susceptibility, Transients, Power Leads
CS112 Electrostatic Discharge Susceptibility
CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection
CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation
CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
RE101 25Hz -100kHz Radiated Emissions, Magnetic Field
RE102 10kHz - 18GHz   Radiated Emissions, Electric Field
RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field
RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field

2, MIL-STD-810H (high and low wide temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, rain, dust, fungus, solar

radiation etc.)
