TECHNICAL SPECIFICATIONS |
Display Size | 10.1 inches, IPS wide viewing angle, with anti-glare AG glass |
Screen Type | Flat Screen |
Resolution | 1920*1080 |
Power Supply | DC18V-36V |
Power Supply Interface | DC24V input |
Display Interface | 1*HDMI |
Material | Aluminum Alloy |
Cabinet Color | Ice grey |
Mounting Solution | Rack mount/Wall mount |
Working:Temperature | -10℃～55℃ |
Storage Temperature | -40℃～60℃ |
ESD | Contact Discharge: ±15KV, Air Discharge: ±15KV |
Electromagnetic Compatibility: |
1, Meet MIL-STD-461G (EMC, EMI, EMS, ESD): |
CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads |
CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads |
CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads |
CS106 Conducted Susceptibility, Transients, Power Leads |
CS112 Electrostatic Discharge Susceptibility |
CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection |
CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation |
CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads |
RE101 25Hz -100kHz Radiated Emissions, Magnetic Field |
RE102 10kHz - 18GHz Radiated Emissions, Electric Field |
RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field |
RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field |
2, MIL-STD-810H (high and low wide temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, rain, dust, fungus, solar radiation etc.) |
