• Intel low-power 6th/7th/8th generation U-series processors • 12.5" LCD display, 1920x1080 resolution • Built-in 8000mAh long-life battery • Vibration and impact resistance, wide temperature operation

RGD-TPC-AX1205T-0001

Detail

TECHNICAL SPECIFICATIONS



ProcessorIntel 6th/7th/8th generation U series processor
MemoryDDR4 16GB, 32GB optional
Harddisk

SSD M.2 interface 256G, other capacities optional

OSWindows7/10, Linux system (optional)
Battery8000mAh
Display

12.5" LCD display, 1920x1080 resolution

Indicator Light

Power indicator light*1, battery indicator light*1,hard disk status indicator light*1

ColorArmy green/Ice grey/Navy grey/Black
Dimension

350.0mm x 230.0mm x 30.0mm

MaterialAluminum alloy
Weight1.7KG
Working Temperature-20℃ ~ +50℃, -40℃ ~ +50℃ optional
Storage Temperature-40℃~ +60℃
Humidity5%~95%RH
Waterproof LevelIP65 (front panel)
Ports

USB3.0*2 standard port, 3.5mm Audio* 1, HDMI* 1 (Type A), SIM* 1,DC 19V (aviation plug),

RJ45* 1 network port 10/ 100/ 1000M
