RGD-KVM-1708HD-VGA

Detail

TECHNICAL SPECIFICATIONS



Computer Connect8 computers, switching cascade can reach 128 units
Port ConnectorUSB & VGA
Control Port Type

USB & VGA

Swith ModeOSD menus, hot keys, buttons
Hot KeysScroll-Lock / Caps-Lock /Num-Lock / KVM OSD
LCD Size

17.3" TFT   LED, Resolution: 1920*1080 @60HZ, Max Color: 16.7M,Brightness: 300nits,

Contrast Ratio: 700:1, 380*215 16:9 / 0.198 x 0.198 mm

Keyboard/Mouse

104 Keys Keyboard   with touchpad

Power Input

Support dual power supply: AC 100-240V~50/60Hz, Or power adapter: 12V 3.33A,

The default AC built-in power supply is shipped.

Actual power consumption18W
OSMicrosoft、Linux、Unix etc. operating system
MaterialROHS
Cabinet ColorHigh-temperature spray Black
Dimension450.0mm x 475.0mm x 44.0mm (L x W x H)
Withdraw Distance45MM
Opening Height325MM
WeightN.W. 10.75KG, G.W. 16.90KG
Working Temperature0℃ ~ +60℃
Storage Temperature-20℃~ +70℃
