RGD-DSP-A09800J-0001

Detail

TECHNICAL SPECIFICATIONS
Display Size:	98 inches, 4K ultra HD, adopt unique ADSDS patent technology
Resolution:	3840*2160
Apect Ratio:	16(H):9(V)
Visual Angle:	178°
Working Frequency:	120Hz
Screen Brightness:	500cd/m2
Screen Display Area：	2158.85(H) x 1214.35(V)
Backlight lifetime：	50000Hrs
Screen Contrast：	1200:1
Chipset：	MSD8386BQM
Built-in Speaker：	15W*2(8Ω)
Port：	3* USB2.0, 2USB, 1AUDIO, 1COAX, 1MIC, 1RJ45 input, 1 RJ45 output, 1* Serial port, 1VGA, 1ATV,
Port：	1Mini AV input, 1 Mini AV output, 4HDMI, 1USB3.0, 1TF card，12.4G WIFI，1*2.4G/5G+BT 4.0
System version:	Android 8.0 and Computer dual system with OPS port
RAM:	3G Byte DDR4
ROM:	32G Byte eMMC flash
Dimension:	22111317120mm
Wall mounting hole position:	Horizontal 800x vertical 400
Mounting Solution:	Wall mounting
Input Power Supply:	100-240V
Power Consumption:	＜600W
Standby Power Consumption:	＜0.5W
Port:	USB
Material:	Explosion-proof tempered glass and CNC stainless steel
Operation humidity:	10%-80%
Working Temperature:	0℃～+40℃
